Designed to accommodate a queen size mattress, the extra width of the Deluxe Plus allows for installation of a refrigerator in the galley kitchen and water tank beneath the chassis. Weighing only slightly more than the Deluxe, the Deluxe Plus is our most popular traditional teardrop model.

All of our trailers are proudly manufactured in compliance with Australian Standards.

SPECIFICATIONS

Tare weight 402 kg | Fully optioned 542 kg
ATM 595 kg
Ball weight 45 kg
GTM 550 kg (AL-KO rubber torsion axle)
14" alloy rims
Tyre size 175/65
50 mm coupling with safety chains

Exterior cabin length 2440 mm
Ground to vent top 1690mm
Wheel arch to wheel arch 2010mm
Coupling to bumper 3430mm
Interior dimensions | 1075 mm H x 2270 mm L x 1515 W (approximately queen bed size)
Floor length 1700 mm
Max stowing length 2200 mm

STANDARD FEATURES

Welded steel tube frame 50 mm x 75 mm with black powder coated finish
Front levelling jockey wheel that pivots
Brushed aluminium wheel arches
Spare wheel
Patterned aluminium stone guard
Laminated fibreglass exterior panels
Choice of two graphics colours from our range
Rear locking hatch with two x 18 kg gas struts
Galley bench in white laminate with additional storage beneath
Left and right entry doors 650 mm x 810 mm with deadlocks, tinted sliding glass and fly screens
Tilt open roof vent with fan, 250 mm square
Fully insulated roof to R-1.2 rating
Carpeted cabin walls and vinyl flooring
Cabin cabinet in white laminate with lift up doors

12v power system
- Four LED lights - galley, cabin ceiling, two cabin reading lights
- External dual colour lights (both sides)
- Battery charger
- Double 12v outlet in cabin and single outlet in galley
- Charging wire from Anderson plug to battery, also suitable for connecting solar panels
240v power system
- External 15 amp caravan inlet
- Circuit breaker/safety switch
- Double power point in galley area and beneath galley bench
- Single power point in cabin cabinet

GRAPHICS COLOUR RANGE

Select any two colours for the graphics on your Little Guy.
